Description
- Data transfer rate: 4800.0 megabits per second
- Hard disk.size: 2.0 TB
- Item dimensions: 5.91 inches
- Special feature: Portable
- Compatible devices: Desktop. Digital storage capacity: 2000.0 GB
Specifications
General Feature
-
Application Client PCs, Game Consoles
-
Capacity 2,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
-
Form Factor M.2 (2280)
-
Interface PCIe Gen 4.0 x4, NVMe 2.0
-
Dimension (Pack: WxHxD) 80 x 22 x 2.3 mm
-
Weight Max 9.0g Weight
-
Storage MemorySamsung V-NAND 3-bit MLC
-
Controller Samsung in-house Controller
- Cache Memory Samsung 2GB Low Power DDR4 SDRAM
Special Feature
-
TRIM Support Supported
-
S.M.A.R.T Support Supported
-
GC (Garbage Collection) Auto Garbage Collection Algorithm
-
Encryption Support AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
-
WWN Support Not supported
- Device Sleep Mode Support Yes
Performance
-
Sequential Read Up to 7,450 MB/s * Performance may vary based on system hardware & configuration
-
Sequential Write Up to 6,900 MB/s * Performance may vary based on system hardware & configuration
-
Random Read (4KB, QD32)Up to 1,400,000 IOPS * Performance may vary based on system hardware & configuration
-
Random Write (4KB, QD32)Up to 1,550,000 IOPS * Performance may vary based on system hardware & configuration
-
Random Read (4KB, QD1)Up to 22,000 IOPS * Performance may vary based on system hardware & configuration
- Random Write (4KB, QD1)Up to 80,000 IOPS * Performance may vary based on system hardware & configuration
Environment
-
Average Power Consumption (system level)*Average: 5.5 W*Maximum: 8.5 W (Burst mode)* Actual power consumption may vary depending on system hardware & configuration
-
Power consumption (Idle)Max. 55 mW * Actual power consumption may vary depending on system hardware & configuration
-
Allowable Voltage 3.3 V ± 5 % Allowable voltage
-
Reliability (MTBF) 1.5 Million Hours Reliability (MTBF)
-
Operating Temperature0 - 70 ℃ Operating Temperature
- Shock1,500 G & 0.5 ms (Half sine)
