Description
- Samsung NVMe SSD powered by the newly designed in-house controller
- Up to 7,450 / 6,900 MB/s sequential read/write speed, Power-efficient SSD
- Experience performance of PCIe Gen 4.0.
Specifications
General Feature
-
Application Client PCs, Game Consoles
-
Capacity 1,000GB (1GB=1 billion bytes by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
-
Form Factor M.2 (2280)
-
Interface PCIe Gen 4.0 x4, NVMe 2.0
-
Dimension (Pack: WxHxD)80 x 22 x 2.3 mm
-
Weight Max 9.0g Weight
-
Storage Memory Samsung V-NAND 3-bit MLC
-
Controller Samsung in-house Controller
- Cache Memory Samsung 1GB Low Power DDR4 SDRAM
Special Feature
-
TRIM Support Supported
-
S.M.A.R.T. Support Supported
-
GC (Garbage Collection)Auto Garbage Collection Algorithm
-
Encryption Support AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
-
WWN Support Not supported
- Device Sleep Mode Support Yes
Performance
-
Sequential Read Up to 7,450 MB/s * Performance may vary based on system hardware & configuration
-
Sequential Write Up to 6,900 MB/s * Performance may vary based on system hardware & configuration
-
Random Read (4KB, QD32)Up to 1,200,000 IOPS * Performance may vary based on system hardware & configuration
-
Random Write (4KB, QD32)Up to 1,550,000 IOPS * Performance may vary based on system hardware & configuration
-
Random Read (4KB, QD1)Up to 22,000 IOPS * Performance may vary based on system hardware & configuration
- Random Write (4KB, QD1)Up to 80,000 IOPS * Performance may vary based on system hardware & configuration
Environment
-
Average Power Consumption (system level)*Average: 5.4 W*Maximum: 7.8 W (Burst mode)* Actual power consumption may vary depending on system hardware & configuration
-
Power consumption (Idle)Max. 50 mW * Actual power consumption may vary depending on system hardware & configuration
-
Allowable Voltage3.3 V ± 5 % Allowable voltage
-
Reliability (MTBF)1.5 Million Hours Reliability (MTBF)
-
Operating Temperature0 - 70 ℃ Operating Temperature
- Shock1,500 G & 0.5 ms (Half sine)
