Description
The Bose Professional PowerMatch PM8500N configurable professional power amplifier provides concert-quality sound with a high level of scalability and configurability for fixed installation sound reinforcement systems. Ethernet-based networking enables configuration, control, and monitoring, and an expansion slot supports input from optional digital audio accessory cards. The front-panel USB connection allows for direct configuration PC connection to a single amplifier. PowerMatch amplifiers utilize numerous Bose Professional technologies to deliver an unprecedented combination of performance, efficiency, and ease of installation—all in a reliable, proprietary design.
- QuadBridge Technology
- Bose Professional ControlSpace Designer software
- Auto-Standby/Auto-Wake function
- Dual voltage and current feedback loop
- PeakBank power supply
- Fast-tracking power factor correction (PFC)
Technical Specification
AMPLIFICATION
-
Channel Separation (Crosstalk): > 65 dB, adjacent channels at 1 kHz
-
Gain, High-Impedance: 42 dB
-
Gain, Low-Impedance: 36 dB, Mono mode / 42 dB, V-Bridge mode / 36 dB, I-Share mode / 42 dB, Quad mode
-
Maximum Peak Power, Symmetrical: 1000 W
-
SNR: > 102 dB (1 dB below rated power, A-weighted)
-
Frequency Response: 20 Hz – 20 kHz (±0.5 dB) at 1 W
-
Number of Channels: 8
-
Power Class: Class D
-
Rated Power, Symmetrical: 450 W per channel at 2 Ω / 500 W per channel at 4 Ω / 300 W per channel at 8 Ω
-
THD+N: < 0.4% at 1 W (20 Hz – 20 kHz)
AUDIO INPUTS, ANALOG
-
Input Channels: 8 balanced, line
-
Connectors: (8) 3-pin Euroblock
-
Input Impedance: > 100 kΩ
-
Maximum Input Level: 24 dBu at 24 dBu sensitivity
-
Sensitivity: 0 dBu, +4 dBu, +12 dBu, +24 dBu, selectable
PHYSICAL
-
Colors: Black
-
Cooling System: Microprocessor-controlled, variable-speed fans, front to rear airflow
-
Suspension/Mounting: Rack-mounting
-
Operating Temperature Range: 0 °C to 40 °C (32 °F to 104 °F)
-
Product Dimensions (H×W×D): 3.5 in × 19.0 in × 20.7 in (88 mm × 483 mm × 525 mm)
-
Net Weight: 28.4 lb (12.9 kg)
-
Rack Spaces: 2
-
Shipping Weight: 34.5 lb (15.7 kg)
